Actuators Spring Opposed Diaphragms Series PD

Add to quote
Categories: ,

Downloads

Specification Document

Design Features

  • High power
  • Fast response.
  • Low stress components.
  • Large variety of sizes.
  • Easily serviceable.
  • Split coupling design for
  • Attachment to valve.
  • Wide range of accessories available.

About Actuators Spring Opposed Diaphragms

  • High power
  • Fast response.
  • Low stress components.
  • Large variety of sizes.
  • Easily serviceable.
  • Split coupling design for
  • Attachment to valve.
  • Wide range of accessories available.

Product Specifications

Actuator TypeSpring Opposed Diaphragm, Manual
Actuator ActionDirect / Reverse Acting
DiaphragmNitrile / Neoprene (nylon reinforced)
Spring RangeSee Table 1
Air Supply20 - 60 PsIG (1.4 - 4.0 Bar)
Air Connection1/4” or 1/2” NPT
AccessoriesValve Positioners - Pneumatic, Electro-Pneumatic, Smart
InstrumentsAirset, Solenoid valve, Volume Booster, Airlock, Limit switches
FeaturesTop Mounted Handwheel, Side Mounted Handwheel, Limit Stops, Removable Blind Head, Steam Jacketing etc...
